Compare
PFD 101
Free-standing dishwasher For large amounts of crockery in households, office tea rooms and utility areas.
- Wash performance: 13 place settings in just 20 min.*Depending on site conditions (temperature of incoming water / power connection) values given may vary.
- 13 % less energy consumption*Based on the ECO programme, compared to predecessor.
- Intuitive to operate thanks to clear control panel design
- Everything completely dry – AutoOpen assisted dryingAutoOpen assisted drying
Completely dry: The dishwasher door opens automatically at the end of the programme. - Flexible loading of load items for the best cleaning resultsFlexLine baskets
Flexibility creates convenience: easy adjustment and flexible loading for the best cleaning results.
Material machine front
Product benefits
Proven hygiene
Effective against viruses – scientifically proven
Our dishwashers in the PFD 10x series remove more than 99.9 %* of all viruses (including coronaviruses).A description of the relevant methodology can be found at the following link:
Quality you can rely on
Long service life
Durability: Miele Professional dishwashers are tested for a long service life.
Subject to technical changes; no liability accepted for the accuracy of the information given! Figures as examples for showing the product benefit.
Cutlery basket
Highly versatile
Extremely versatile: The cutlery basket fits in any position over the front spikes in the lower basket.
Subject to technical changes; no liability accepted for the accuracy of the information given! Figures as examples for showing the product benefit.
Subject to technical changes; no liability accepted for the accuracy of the information given! Figures as examples for showing the product benefit.
FlexiTimer with EcoStart
Protects your wallet and the environment
Clever: with EcoStart, the dishwasher automatically selects the cheapest electricity tariff every time.
Subject to technical changes; no liability accepted for the accuracy of the information given! Figures as examples for showing the product benefit.
Proven hygiene
Effective against viruses – scientifically proven
Our dishwashers in the PFD 10x series remove more than 99.9 %* of all viruses (including coronaviruses).A description of the relevant methodology can be found at the following link:
Proven hygiene
Effective against bacteria – scientifically proven
Our dishwashers in the PFD 10x series remove 99.999 %* of most bacteria.The hygiene certificate can be found
Subject to technical changes; no liability accepted for the accuracy of the information given! Figures as examples for showing the product benefit.
Subject to technical changes; no liability accepted for the accuracy of the information given! Figures as examples for showing the product benefit.
Quality you can rely on
Long service life
Durability: Miele Professional dishwashers are tested for a long service life.
Commercial throughflow heater
Full-size power
A stainless steel through-flow water heater with maximum 2 x 3 kW capacity ensures high heating performance.
Water protection guarantee*For details please refer to our warranty terms and conditions for water protection.
Waterproofing - guaranteed
Peace of mind: Miele will bear the cost for damage resulting from a defect in the water system.
Subject to technical changes; no liability accepted for the accuracy of the information given! Figures as examples for showing the product benefit.
Subject to technical changes; no liability accepted for the accuracy of the information given! Figures as examples for showing the product benefit.
Product details
PFD 101
EAN 4002516446132 / Article number 61010110GB / Material number 11807820
EAN 4002516446132 / Article number 61010110GB / Material number 11807820
| Construction type | Freestanding dishwasher, front loader Free-standing dishwasher For freestanding installation, independent of an existing run of kitchen units. |
|---|---|
| Range | ProfiLine |
| Wash system | Fresh water front loader Fresh water system Constantly high cleaning performance and hygiene thanks to repeated water changes. |
| Number of levels | 2 |
| Front | Brilliant white |
| Lid | Plastic |
| Side panels | Brilliant White |
| Fascia color | CleanSteel |
| Suitable for guesthouses | |
|---|---|
| Suitable for child care facilities | |
| Suitable for universities and schools | |
| Suitable for offices | |
| Suitable for domestic use | |
| Suitable for small businesses | |
| Suitable for sports clubs |
| Tested virucidal efficacy | Effective against viruses – scientifically proven According to the InFluenc_H – Institute for Integrative Hygiene and Virology, cleaning with dishwashers from the PFD 10x series using Miele’s ProCare Shine 11 OB and 12 GC cleaning agents removes enveloped and non-enveloped viruses (e.g. coronavirus, influenza or noroviruses) in the Intensive and Hygiene programmes, as well as enveloped viruses (but not the hepatitis B virus) in the Short and Universal programmes, even if load items are difficult to reprocess. |
|---|---|
| Proven hygiene | Effective against bacteria – scientifically proven In the “SHORT” and “ECO” programme, the Miele ProfiLine fresh water dishwashers meet the hygiene requirements for type testing based on DIN 10512, which corresponds to a bacteria reduction of at least 5 log10. This decontamination performance means that the machines fulfil the criteria according to which InFluenc_H – the Institute for Integrative Hygiene and Virology awards its “TESTED HYGIENE QUALITY” seal. |
| Circulation pump Qmax in l/min. | 75 |
| Shortest programme duration in min. Performance data The values quoted may vary depending on the on-site conditions (power connection/water intake temperature). | 20 |
| Maximum final rinse temperature in °C | 82 |
| Cleaning performance, place settings/cycle Performance data The values quoted may vary depending on the on-site conditions (power connection/water intake temperature). | 13 |
| Service life in wash cycles Note Our machines undergo intensive testing under laboratory conditions. The actual number of wash cycles may vary depending on actual usage behaviour, maintenance and care of the machine. | 12500 |
| Control system | Electronic controls |
|---|---|
| Programme selection | Programme selector buttons |
| Max. delay start in h | 24 |
| Time left display | |
| Dishwashing programmes [number] | 8 |
| Programme sequence indicator | |
| Choice of display language | |
| Check filter indicator |
| Electrical connection | AC 230V 50HZ |
|---|---|
| Heater rating in kW | 6.1 |
| Total connected load in kW | 6.3 |
| Fuse rating in A | 32 |
| Length of mains connection cable in m Note The length refers to the supply lead on the outside of the appliance. | 1.7 |
| Electrical connection | AC 230V 50HZ |
|---|---|
| Heater rating in kW | 1.9 |
| Total connected load in kW | 2.1 |
| Fuse rating in A | 13 |
| Cold or hot water [number] | 1 |
|---|---|
| Required flow pressure in bar | 1-10 |
| Drain pump [DN] | 22 |
| Drain pump head height from floor level, max. in c | 100 |
| Integrated water softener | |
| Maximum water hardness in mmol/l Note With a water hardness level of 0.53 mmol/l and above, the installation of a pre-connected water softener is recommended if an integrated water softener is not already available. | 6.5 |
| Water protection system | Waterproof system Water protection guarantee* Peace of mind: Miele will bear the cost for damage resulting from a defect in the water system.For details please refer to our warranty terms and conditions for water protection. |
| Length of water inlet hose in cm | 150 |
| Length of water drain hose in cm | 150 |
| External dimensions, height in mm Note The dimension refers to the appliance height without the feet extended. | 845 |
|---|---|
| External dimensions with lid, height in mm Note The dimension refers to the appliance height without the feet extended. | 845 |
| External dimensions, net width in mm | 598 |
| External dimensions, net depth in mm | 570 |
| External dimensions, gross height in mm Note Including packaging | 970 |
| External dimensions, gross width in mm Note Including packaging | 670 |
| External dimensions, gross depth in mm Note Including packaging | 670 |
| Usable space in wash cabinet, height in mm | 540 |
| Usable space in wash cabinet, width in mm | 510 |
| Usable space in wash cabinet, depth of upper baske | 450 |
| Usable space in wash cabinet, depth of lower basket in mm | 450 |
| In-feed height above floor in mm | 210 |
| Required niche width in mm | 600 |
| Net weight [kg] | 60 |
| Gross weight in kg Note Including packaging | 67 |
| Maximum floor load in N/m² Maximum floor bearing capacity Maximum floor bearing capacity states the maximum weight (N) that can be placed on the supporting surface on which the machine is installed. This maximum load bearing capacity is the result of adding up the weight of the machine, the load and the water in it, as well as the dynamic forces that occur during operation. | 1000 |
| Emissions – sound pressure at workplace Emissions - sound pressure at workplace The emission sound pressure level depends on the programme and is a value given to the noise created by the machine. Miele Professional appliances have very low noise levels. | 33 dB(A) re 20 µPa |
|---|---|
| Sound power (LwA) in dB(A) re 1 pW Note The sound power level depends on the programme. | 0 |
| Universal | |
|---|---|
| Short | |
| Hygiene | |
| Cold/Pre-wash | |
| Glasses | |
| Plastics | |
| Energy save/Eco | |
| Intensive |
| ExtraComfort P baskets | |
|---|---|
| Flexible FlexLine basket design | |
| FlexCare glass holder [number] | 2 |
| FlexCare cup rack [number] | 1 |
| Cutlery basket | |
| Height-adjustable upper basket | |
| Combinable with APFD 210 bottle basket |
| Drying | Active condensation drying Active condensation drying Condensation drying with the help of cool room air. Extra drying Additional drying For particularly quick programme cycles: Additional drying only if needed. AutoOpen assisted drying AutoOpen assisted drying Completely dry: The dishwasher door opens automatically at the end of the programme. |
|---|---|
| 1 combi dispenser in the door for powder cleaning agent and rinsing agent | |
| Wash cabinet made from high-quality stai | |
| AutoClose | |
| EcoFeedback | |
| Brilliant GlassCare | |
| Safety lock | |
| Adjustable final rinse temperature | |
| Optical interface | |
| SmartStart | |
| FlexiTimer with EcoStart | |
| WiFi |
| Load size of the ECO programme in place settings | 13 |
|---|---|
| Energy efficiency class (A–G) | E |
| Energy consumption of the ECO program per 100 cycles | 93 |
| Water consumption of the ECO programme per cycle in l | 12 |
| Acoustic airborne noise emission class (A–D) | C |
| Acoustic airborne noise emission in dB(A) re 1 pW | 46 |
| Programme running time of the ECO programme in min | 250 |
| CE | |
|---|---|
| Complies with Machinery Directive 2006/42/EC | |
| VDE | |
| EMC radio suppressed | |
| DIN EN 17735 | |
| EN 1717 | |
| UKCA |
