Fully integrated XXL dishwasher with 3D+ cutlery tray

PG 8133 SCVi Without front

For large amounts of crockery in households, office tea rooms and utility areas.


sale price€4,452.60



Product details

  • Wash performance: 14  place settings in just 17 min.4,
  • Requires an electrical connection for AC 230V 50HZ
  • Perfect lighting for easy loading -BrilliantLight
  • The best care for your glasses –Perfect GlassCare
  • Everything completely dry –AutoOpen assisted drying
  • Easy communication –WiFi Conn@ct

Product data sheet

Construction typeFully integrated dishwasher
XXL dishwashers
RangeProfiLine
Wash systemFresh water front loader
Number of levels2
FrontWithout front
Side panelsGalvanised
Suitable for hospitals
Suitable for guesthouses
Suitable for universities and schools
Suitable for offices
Suitable for domestic use
Suitable for small businesses
Suitable for sports clubs
Circulation pump Qmax in l/min.190
Shortest programme duration in min.17
Maximum final rinse temperature in °C82
Cleaning performance, place settings/cycle14
Control systemElectronic controls
Programme selectionProgramme selector buttons
Max. delay start in h24
Time left display
Choice of display language
Electrical connectionAC 230V 50HZ
Heater rating in kW6.50
Total connected load in kW6.70
Fuse rating in A32
CEE plug
Length of mains connection cable in m1.70
Electrical connectionAC 230V 50HZ
Heater rating in kW2.10
Total connected load in kW2.30
Fuse rating in A13
Cold or hot water [number]1
Required flow pressure in bar0.30-10
Drain pump [DN]22
Drain pump head height from floor level, max. in c100
Integrated water softener
Maximum water hardness in mmol/l6.50
Water protection systemWaterproof system
External dimensions, height in mm845
External dimensions, net width in mm598
External dimensions, net depth in mm570
External dimensions, gross height in mm970
External dimensions, gross width in mm670
External dimensions, gross depth in mm690
Usable space in wash cabinet, height in mm540
Usable space in wash cabinet, width in mm510
Usable space in wash cabinet, depth of upper baske450
Usable space in wash cabinet, depth of lower basket in mm450
In-feed height above floor in mm210
Net weight [kg]56
Gross weight in kg65
Maximum floor load in N/m²1000
Emissions – sound pressure at workplace38 dB(A) re 20 µPa
Sound power (LwA) in dB(A) re 1 pW45
Heat dissipation into the room in MJ/h2.52
Universal
Short
Hygiene
Cold/Pre-wash
Glasses
Plastics
Energy save/Eco
Intensive
MaxiComfort baskets
Patented 3D+ cutlery tray
DryingExtra drying
1 combi dispenser in the door for powder cleaning agent and rinsing agent
Wash cabinet made from high-quality stai
BrilliantLight
ComfortClose
Perfect GlassCare
Adjustable final rinse temperature
Optical interface
SmartStart
FlexiTimer with EcoStart
MobileControl
ShopConn@ct
WiFi
Load size of the ECO programme in place settings14
Energy efficiency class (A–G)E
Energy consumption of the ECO program per 100 cycles95
Water consumption of the ECO programme per cycle in l13.80
Acoustic airborne noise emission class (A–D)C
Acoustic airborne noise emission in dB(A) re 1 pW45
Programme running time of the ECO programme in min216
External dispensing module for liquid detergent
CE
Complies with Machinery Directive 2006/42/EC
EMC
Interference suppression
VDE
DIN EN 17735
EN 1717
EAN4002515818831

Connectivity

Convenience and efficiency in demanding situations
Future-proof networking via WiFi

Fully informed with a high-performance network connection.


Efficiency and sustainability

Optional dispensing of liquid agents
Connection for detergent dispenser module

An optional dispenser module can be connected for convenient and economical use of liquid agents.


Economical
Low consumption values

Economical and efficient: Miele Professional dishwashers stand out with low consumption values.


Ensures the optimum water hardness level
Integrated water softener

The built-in softener ensures the optimum hardness level of the water for perfect dishwashing results.


Professional and effective
Highly effective filter system

Outstanding dishwashing results and reliability are largely due to the highly effective filter system.


Protects your wallet and the environment
FlexiTimer with EcoStart

Clever: with EcoStart, the dishwasher automatically selects the cheapest electricity tariff every time.


Save money intelligently
SmartStart

Practical: this function sets the machine to work automatically when electricity is at its cheapest.


Hygiene

Maximum hygiene assurance
Fresh water system

Constantly high cleaning performance and hygiene thanks to repeated water changes.


Performance

Dishwashing professionals for daily dish mountains
For businesses

These dishwashers are ideally suited for all areas which deal with large amounts of crockery.


For dry crockery in next to no time
AutoOpen assisted drying

Completely dry: The dishwasher door opens automatically at the end of the programme.


A gentle way to a perfect shine
Perfect GlassCare

A gentle way to a perfect shine: With Perfect GlassCare, your glasses are thoroughly and gently cleaned.


Lots of space
XXL lab washers

Large capacity dishwasher with a height of 85 cm, giving you even more room in the upper basket.


Effective drying
Recirc.-condensation drying

Crockery is dried very effectively using cool room air.


Quality

Full-size power
Commercial throughflow heater

A stainless steel through-flow water heater with maximum 2 x 3 kW capacity ensures high heating performance.


A strong combination
Powerful heater pump

For maximum cleaning performance, every dishwasher is equipped with a powerful heater pump.


Waterproofing - guaranteed
Water protection guarantee1,

Peace of mind: Miele will bear the cost for damage resulting from a defect in the water system.


Long service life
Quality you can rely on

Durability: Miele Professional dishwashers are tested for a long service life.


User convenience

An eye on the time
Delay start and countdown indicator

For maximum flexibility, a delay start time of up to 24 hours can be selected.


Brilliant visibility
BrilliantLight2,

Brilliant visibility: Four LEDs illuminate the entire interior cabinet for easy loading and unloading.


The best door concept of our time
ComfortClose

Convenient: The door can be closed very easily.


Your dishwasher “speaks” multiple languages
Selectable display languages

All-rounder: you can choose the language for the display so that you fully understand everything.


Basket design

Unique versatility for perfect cutlery care
Patented 3D+ cutlery tray3,

Greater flexibility: the middle section with hinged row of spikes can be lowered, offering space for large items.


Maximum flexibility
MaxiComfort baskets

Perfect rinsing and drying results thanks to integrated premium baskets.


  • 1.For details please refer to our warranty terms and conditions for water protection.
  • 2.Patent: EP 2 233 061 B1
  • 3.German patent DE102008062761B3 <lt> </lt> br <gt> </gt> European patent EP2201887B1
  • 4.Depending on site conditions (temperature of incoming water / power connection) values given may vary.

We reserve the right to make technical changes; we assume no liability for the accuracy of the information provided.
