125 Day Money-Back Guarantee on all Laundry, Freestanding Coffee and Cylinder Vacuum Cleaners

Home
Hobs
SmartLine
CS 7101-1 FL

SmartLine element

CS 7101-1 FL Black

Name: CS 7101-1 FL
Brand: Miele
SKU: 11402720
Price: 1649.99 EUR
Availability: OutOfStock

with a dual wok burner

Product data sheet

€1,649.99

A contribution to recycling costs (PRF) of 5 EUR for large domestic appliances and 10 EUR for American Side by Side refrigeration is Included in the retail price. No fees apply to Vacuum Cleaners, Accessories, Hobs, Microwaves, Hoods or Coffee Machines.

Additional services

You can select the following services for this product in your basket:

Built-In Installation (€70.00)
WEEE Collection (€0.00)

Product details

Simple controls -single-handed operation via rotary dial control
Elegant design – for flush or raised installation
Seamlessly integrates with anySmartLine element
Broad performance spectrum - dual wok with up to 4.500 kW kW of power
Easy cleaning - dishwasher-safe ComfortClean pot rests

Product data sheet

Heating typeGas

SmartLine

Elegant glass ceramic surface

Ceramic surface colourBlack

Flush

Surface-mounted installation

Cast iron pot rests (matt black enamelled)

Number of cooking zones1

Dual wok burner in kW4.50

PositionCentred

TypeDual wok burner

Size in mmØ 300

Max. rating in W4500

Operation via sensor controlsKnob

Operation via knobs

Electronic ignition with single-hand operation

Easy to clean ceramic glass

Dishwasher-proof pot rests

GasStop

Dimensions in mm (width)378

Dimensions in mm (height)92

Casing height incl. connection box in mm92

Dimensions in mm (depth)520

Cutout dimensions in mm (width) with surface-mounted installation358

Cutout dimensions in mm (depth) with surface-mounted installation500

Internal cutout dimensions in mm (width) with flush installation358

Internal cutout dimensions in mm (depth) with flush installation500

External cutout dimensions in mm (width) with flush installation382

External cutout dimensions in mm (depth) with flush installation524

Weight in kg7

Total rated load in kW4.500

Position of gas connectionHinten links

Voltage in V220-240

Frequency in Hz50-60

Length of supply lead in m1.4

CSFG 7000 FlameGuard

Mains cable

Jets for natural gas

Jets for liquid gas

Wok ring

EAN4002516306245

What's included

CSFG 7000 FlameGuard

Mains cable

Jets for natural gas

Jets for liquid gas

Wok ring

Efficiently protects and makes cleaning easier

ComfortClean pot rests

Fast cleaning: remove the pot rests and wash in the dishwasher. Keeps gas hobs looking good for longer.

Flame failure monitor for maximum safety

GasStop

Reassuring: if the flame is extinguished, for example by a draught, the continued supply of gas is prevented.

Perfect wok cooking on gas

Wok burner

Professional: powerful wok burner for uniform and/or separate power regulation of both flame rings.

Safety

Flame failure monitor for maximum safety

GasStop

Reassuring: if the flame is extinguished, for example by a draught, the continued supply of gas is prevented.

Features

Perfect wok cooking on gas

Wok burner

Professional: powerful wok burner for uniform and/or separate power regulation of both flame rings.

Design

Design in detail

Metal knobs

Perfect convenience: the gas elements can be intuitively operated via high-quality metal knobs.

User convenience

Easy ignition of the flame

Electronic ignition with single-handed operation

No need for matches or lighters: automatic ignition of burners thanks to intelligent technology.

Maintenance

Efficiently protects and makes cleaning easier

ComfortClean pot rests

Fast cleaning: remove the pot rests and wash in the dishwasher. Keeps gas hobs looking good for longer.

Matching products and accessories

CSZL 7000

Spacer strip

for installing several SmartLine elements in one single cut-out.

GP CL KM 0252 L

Ceramic and stainless steel cleaner, 250 ml

For best cleaning results and safe use.

GP MI X 0011 W

Multi-purpose microfibre cloth, qty 1

For best cleaning results and safe use.

GP GS KM 0011 M

Scraper for cleaning

For ceramic glass hobs.

GP MI S 0031 W

MicroCloth kit, 3 pieces

For best cleaning results and safe use.

iittala cookware, set of 4 pans

from the "All Steel" range by Harri Koskinen, satin finish exclusively f. Miele.

KMTS 5704-2

Fiskars “All Steel” starter pan set (4 pieces)

stainless steel cookware with a matt brushed finish exclusively for Miele.

CSZL 7000

Spacer strip

for installing several SmartLine elements in one single cut-out.

iittala frying pan with nonstick coating

from the matt brushed “All Steel” range, exclusively by Miele.

MicroCloth HyClean, 1 cloth

Antibacterial multi-purpose cloth for improved hygiene.

GP GSB KM 0101 M

Replacement blades, 10 pieces

For cleaning scraper.

Downloads

Operating instructions/Installation instructions

PDF

Downloads

Warranty conditions

PDF

Downloads

Product sheet

PDF

Downloads

dwg

ZIP

Downloads

ifc

ZIP

Downloads

rvt

ZIP

Downloads

fbx

ZIP

Downloads

rfa

ZIP

Downloads

Product fiche

PDF

Downloads

Whether you are looking to replace an appliance or plan a new kitchen – you will find all the relevant installation drawings for your Miele appliance here. Please note that our products should only be installed and maintained by authorised experts. In the event of queries, please ring us for some no-obligation advice!

https://media.miele.com/images/2000013/200001320/20000132001.png

Descriptions

CS7101FL, CS7101-1FL flush (installation drawing)

1) Front, 2) Mains connection box with mains connection cable, L = 2000 mm, 3) Stepped cut-out, 4) Wooden frame 12 mm (supplied loose), 5) Gas connection R 1/2 - ISO 7-1 (DIN EN 10226)

Downloads

1.A contribution to recycling costs (PRF) of 5 EUR for large domestic appliances and 10 EUR for American Side by Side refrigeration is Included in the retail price. No fees apply to Vacuum Cleaners, Accessories, Hobs, Microwaves, Hoods or Coffee Machines.

We reserve the right to make technical changes; we assume no liability for the accuracy of the information provided.
