Slimline cooker hood
DAS 2920 Stainless steel
with EasySwitch controls for convenient operation
Colour:Stainless steel
sale price€729.99
A contribution to recycling costs (PRF) of 5 EUR for large domestic appliances and 10 EUR for American Side by Side refrigeration is Included in the retail price. No fees apply to Vacuum Cleaners, Accessories, Hobs, Microwaves, Hoods or Coffee Machines.
Retail price includes 23% VAT.
Product details
- Classic design – stainless steel panel, 90 cm wide
- LED strip for uniform lighting
- Efficient filtration-10-ply stainless-steel grease filter
- Safe and easy to clean -Miele CleanCover
- Recirculation mode –Active AirClean or Longlife AirClean filter
Slimline cooker hood
Type of air guideCan be retrofitted
Recirculation conversion kit (order separately)DUU 151,DUU 150
Active charcoal filter (order separately)
- DKFS 31-R
- DKFS 31-P
ColourStainless steel
Electronic controls
Touch-on-glass controls
ControlsEasySwitch
Booster levels1
Easy-to-clean canopy interior – CleanCover
Energy efficiency class (A+++ to D)A
Annual energy consumption in kWh/year42
Fluid dynamic efficiency classA
Lighting efficiency classA
Grease filtering efficiency classA
Easy-to-clean canopy interior – CleanCover
Number of dishwasher-safe stainless steel grease filters (10-ply)1
LED
Number x W1 x 3,2 W
Light intensity in Lx275 lx
Colour temperature in K3500 Kelvin
Dual-action blower
AC motor
Air throughput in Level 1 (m³/h) according to EN 61591195
Air throughput in Level 2 (m³/h) according to EN 61591295
Air throughput in Level 3 (m³/h) according to EN 61591410
Air throughput in booster level 1 (m³/h)555
Sound power in Level 1 (dB(A) re 1 pW) according to EN 60704-347
Sound power in Level 2 (dB(A) re 1 pW) according to EN 60704-354
Sound power in Level 3 (dB(A) re 1 pW) according to EN 60704-361
Sound power in Booster level 1 (dB(A) re 1 pW) acc. to EN 60704-369
Sound pressure in Level 1 (dB(A) re 20 µPa) according to EN 60704-2-1333
Sound pressure in Level 2 (dB(A) re 20 µPa) according to EN 60704-2-1340
Sound pressure in Level 3 (dB(A) re 20 µPa) according to EN 60704-2-1347
Sound pressure in Booster level 1 (dB(A) re 20 µPa) acc. to EN 60704-2-1355
Air throughput in Level 1 (m³/h) according to EN 61591190
Air throughput in Level 2 (m³/h) according to EN 61591290
Air throughput in Level 3 (m³/h) according to EN 61591415
Air throughput in Booster level 1 (m³/h) according to EN 61591550
Sound power in Level 1 (dB(A) re 1 pW) according to EN 60704-352
Sound power in Level 2 (dB(A) re 1 pW) according to EN 60704-360
Sound power in Level 3 (dB(A) re 1 pW) according to EN 60704-368
Sound power in Booster level 1 (dB(A) re 1 pW) acc. to EN 60704-375
Sound pressure in Level 1 (dB(A) re 20 µPa) according to EN 60704-2-1338
Sound pressure in Level 2 (dB(A) re 20 µPa) according to EN 60704-2-1346
Sound pressure in Level 3 (dB(A) re 20 µPa) according to EN 60704-2-1354
Sound pressure in Booster level 1 (dB(A) re 20 µPa) acc. to EN 60704-2-1361
Safety shut-off
Canopy width in in. (mm)896
Canopy height in in. (mm)36
Depth of hood canopy in in. (mm)273
Minimum height above electric hobs in mm450
Minimum safety distance above gas hobs (max. 12.6 kW total power, burner ≤ 4.5 kW) in mm650
Net weight in kg14
Length of supply lead in m1.5
Standard plug fitted
Total rated load in kW0.203
Voltage in V230
Fuse rating in A10
Frequency in Hz50
Number of phases1
Extraction ducting connection at top
Diameter of extraction ducting connection in mm150
Non-return flap
EAN4002516495888
Non-return flap
Easy to use and effective against grease
Stainless steel grease filters (10-layer)
Looks great and does a good job: effective grease filtering and easy cleaning in a dishwasher.
Convenience and safety in detail
Miele CleanCover
Protection and easy cleaning: the smooth concealed surface prevents contact with electrical components and motor.
Always on the safe side
Safety switch-off
Sensible, even in case of operating errors: the cooker hood switches off automatically after 10 hours.
Easy to use and effective against grease
Stainless steel grease filters (10-layer)
Looks great and does a good job: effective grease filtering and easy cleaning in a dishwasher.
Convenience and safety in detail
Miele CleanCover
Protection and easy cleaning: the smooth concealed surface prevents contact with electrical components and motor.
Matching products and accessories
Downloads
Whether you are looking to replace an appliance or plan a new kitchen – you will find all the relevant installation drawings for your Miele appliance here. Please note that our products should only be installed and maintained by authorised experts. In the event of queries, please ring us for some no-obligation advice!
Descriptions
DAS2920, DAS2920EXTA, DAS2922Living, DAS4920, Installation drawings
1) The front section of the wall unit must be fitted with a base panel to secure the cooker hood. If the appliance is fitted further back, e.g. to accommodate a front panel, then the shelf depth should be deeper accordingly. , 2) If a partition wall is to be provided in the unit, it must be removable., 3) Extraction, recirculation with conversion kit DUU 150., 4) Mounting is also possible in a 600 mm wide cabinet., * In this installation situation, the deflector plate is flush with the front edge of the housing unit carcase. , If you wish to position the cooker hood further forward or further back (e.g. because it has a front panel), dimensions have to be adapted accordingly., , Extraction: the height of the wall unit and the cut-out dimensions must take into account any accessories fitted, e.g. silencer, recirculation hood conversion kit). - 1.A contribution to recycling costs (PRF) of 5 EUR for large domestic appliances and 10 EUR for American Side by Side refrigeration is Included in the retail price. No fees apply to Vacuum Cleaners, Accessories, Hobs, Microwaves, Hoods or Coffee Machines.
