Heat-pump dryers

PDR 1108 SmartBiz HP [EL]

meets industry standards with simple and flexible installation without ducting.


sale price€2,509.20



Product details

  • Drum volume 120 l, load capacity 8 kg
  • 50 % less energy consumption than vented dryers5,
  • High-quality stainless steel fascia plus Mielehoneycomb drum
  • Supplied ready for connection incl. mains plug
  • Space-saving installation aswasher-dryer stack

Product data sheet

Construction typeFront-loader, stackable
RangeSmartBiz
FrontLotus white
Load in kg8
Drum volume in l120
Drying systemHeat pump
Door opening [Ø] in mm370
Door opening angle in degrees167
Door hingeleft
Stainless steel honeycomb drum
Suitable for the hotel and catering industry
Suitable for small businesses
Suitable for universities, nurseries, and schools
Suitable for sports clubs
Suitable for beauty salons, spas, and fitness centres
Suitable for domestic use
Maximum evaporation capacity in l/hour2 l
Specific energy consumption for Cottons/Normal drying programme with residual moisture at 48 % in kW0.14
Specific energy consumption for mixed fibre fabrics/Normal drying programme with residual moisture a0.12
Programme duration in min.134
Programme duration for Cottons/Normal drying programme with residual moisture at 48 % in minutes134
Programme duration for mixed fibre fabrics/Normal drying programme with residual moisture at 40 % in112
Tested operating hours15000
Control systemDirectSensor 7-segment
User interfaceResidual moisture controlled
Max. delay start in h24
Time left display
Fascia panel with plain text
Heating typeHeat pump
Electrical connection220-240V~ 50HZ
Total connected load in kW1.10
Fuse rating in A13
External dimensions, height in mm850
External dimensions, width in mm596
External dimensions, depth in mm636
External dimensions, gross height in mm940
External dimensions, gross width in mm660
External dimensions, gross depth in mm690
Net weight in kg53.50
Gross weight in kg58
Maximum floor load in N920
Emission sound pressure level in the workplace<lt/>70 dB(A) re 20 µPa
Heat dissipation into the room in MJ/h1.79
Axial airflow
Fluff filter in the door
SmartBiz heat exchanger filter system
PerfectDry
Wash2Dry
SoftLift drum ribs
Gentle tumble function
Condensed water drainage
FragranceDos
Drum lighting
Machine-independent accessories
Energy efficiency classA+++
Condensation efficiency classA
Annual energy consumption in kWh161
Noise in dB(a) in the Cottons Normal dry standard programme with a full load67
Duration in minutes in the standard programme165
How it worksCondenser
Load in kg8
Recycling rate in %95
Hermetically sealed system
CoolantR290
Refrigerant quantity in kg0.14
Refrigerant global warming potential in kg CO2e3
Appliance global warming potential in kg CO2e0.42
Optical interface for service access
WiFiConn@ct
CE
VDE
VDE-EMC
Splash-proof safety rating IPX4
WEEE
UKCA
Complies with Machinery Directive 2006/42/EC
EAN4002516798675

Connectivity

Future-proof connections
WiFiConn@ct

Simple networking via WiFiConn@ct: connect via smartphone/tablet and app1, and retrieve status updates.


Efficiency and sustainability

Economical and efficient
Low consumption values

Economical and efficient: Miele Professional commercial laundry machines impress with low consumption values.


More capacity for the best results
Large capacity

The large capacity drum ensures perfect drying results even with large loads.


Minimal energy consumption
Energy-saving heat-pump system2,

Approx. 50% reduction in energy consumption thanks to pioneering heat-pump technology.


Heat pump is now even more sustainable
Refrigerant: propane

The use of propane as a refrigerant reduces the GWP (global warming potential) by up to 99.8 %.


Performance

Quick and efficient
Short programme cycles

Premium commercial technology allows you to benefit from the shortest programme cycles.


Perfect drying results
PerfectDry system

On the basis of a constant residual moisture measurement, the PerfectDry system perfectly dried garments.


Outstanding drying results
Axial airflow

For perfect drying results, air is passed through the drum according to the principle of longitudinal air flow.


Quality

Ultimate quality
Excellent durability

Professional technology ensures excellent reliability and durability for daily work routine.


User convenience

Well-planned laundry care
Delay start up to 24 hours

The programme start time can be pre-set up to 24 hours in advance for efficient planning.


An eye on the time
Countdown indicator

After the programme has started, the display shows the cycle time remaining.


Washing & drying on less than 0.5 m² of fl. sp.
Washer-dryer stack

High performance in the smallest space: Installation as washer-dryer stack requires less than 0.5 m² floor space.


Let there be light
Drum lighting

No laundry item is overlooked when unloading thanks to the perfectly lit honeycomb drum.


Clear and concise
Clear text display in country-specific language

Programme names and other information are displayed as clear text in country-specific languages


Simple drainage of condensed water
Patented condensate drainage3,

Emptying not necessary: The condensed water can be drained directly via a hose.


Safety down to the last detail
SmartBiz heat exchanger filter system

For easy cleaning: a low-maintenance filter system protects the heat exchanger from dust particles.


Effective and easy to clean
Convenient fluff filter4,

Easy to access: the second fluff filter reliably captures fluff and is easy to clean.


The cleverly networked laundry care team
Wash2Dry*

Hand in hand: your tumble dryer automatically uses the same programme as your washing machine.


Gentle laundry care

Unique honeycomb structure for gentle fabric care
Honeycomb drum

Less creasing, easy finishing: Laundry is dried very gently and evenly in the honeycomb drum.


Take it with you
SoftLift drum ribs ensure gentle fabric care

The SoftLift drum ribs allow laundry to be dried gently and evenly.


Laundry is loosened automatically
Perfect anti-crease action

The laundry is tumbled regularly after the end of the programme to protect it from creasing.


  • 1.The Mobile app is available separately – its availability depends on the country or region.
  • 2.The heat pump contains fluorinated greenhouse gases in a hermetically sealed system.
  • 3.Patent: EP 1 186 697 B1
  • 4.European patent: EP2273005
  • 5.Heat pump dryers consume up to 50 % less energy than an electrically heated vented dryer.

We reserve the right to make technical changes; we assume no liability for the accuracy of the information provided.
