Built-in freezer
FNS 7710 E
with NoFrost and 8 freezer drawers for max. convenience.
sale price€1,899.99
A contribution to recycling costs (PRF) of 5 EUR for large domestic appliances and 10 EUR for American Side by Side refrigeration is Included in the retail price. No fees apply to Vacuum Cleaners, Accessories, Hobs, Microwaves, Hoods or Coffee Machines.
Retail price includes 23% VAT.
Product details
- No icing up of food and no need to defrost thanks toNoFrost
- Food is frozen quickly and gently –SuperFreeze
- Flexible increase in freezer volume –VarioRoom
Freezer
Built-in appliance
Integrated appliance
Door hingeLeft
Convertible door hinging
Side-by-side enabled
Networking with Miele@home
NoFrost
VarioRoom
Operating conceptSensorTouch
SuperFreeze
No. of temperature zones1
Sabbath mode
Party mode
Number of freezer drawers8
Energy efficiency class (A–G)E
Annual energy consumption in kWh237.25
Energy consumption in 24 h in kWh0.65
Lock function
Acoustic door alarm
Acoustic temperature alarm
Optical temperature alarm
Power cut indication for freezer section
Niche width in mm min.560
Niche width in mm max.570
Niche height in mm min.1772
Niche height in mm max.1788
Niche depth in mm550
Appliance width in mm559
Appliance height in mm1770
Appliance depth in mm546
Weight in kg58.50
Door hinge technologyFixed door
Max. door front weight – refrigerator, in kg26
Climate classSN-T
4* freezer compartment in l213
Total usable capacity in l213
Storage time in case of fault in h9
Freezer capacity in kg/24 h12
Acoustic airborne noise emission class (A–D)B
Sound emissions in dB(A) re 1 pW33
Current consumption (mA)1300
Voltage in V220.00-240.00
Fuse rating in A10
Number of phases1
Frequency in Hz50.00-60.00
Length of supply lead in m2.20
Replacing lampsService
Ice cube tray
EAN4002516797517
Ice cube tray
Defrosting is a thing of the past
NoFrost
No more defrosting: the circulation cooling system prevents ice from developing, saving the hassle of defrosting.
Downloads
Whether you are looking to replace an appliance or plan a new kitchen – you will find all the relevant installation drawings for your Miele appliance here. Please note that our products should only be installed and maintained by authorised experts. In the event of queries, please ring us for some no-obligation advice!
Descriptions
K7733E, K7763E, K7732E, K7734F, K7764E, K7743E, K7744E, K7773D, K7774D, side view (installation drawings)
Installation drawings
Descriptions
K7733E, K7763E, K7732D, K7732E, K7734F, K7764E, K7743E, K7744E, K7773D, K7774D, built-in (footnote*) (drawings)
*The declared energy consumption was calculated in a 560 mm deep niche. The appliance is fully functional in a 550 mm niche but the energy consumption will be slightly higher.
Descriptions
K7733E, K7763E, K7732E, K7734F, K7764E, K7743E, K7744E, K7773D, K7774D (footnote*) (installation drawings)
*1. View from the front, 2. Mains connection cable, L = 2100 mm, 3. Ventilation cut-out min. 200 cm², 4. Ventilation, 5. No connections permitted in this area - 1.A contribution to recycling costs (PRF) of 5 EUR for large domestic appliances and 10 EUR for American Side by Side refrigeration is Included in the retail price. No fees apply to Vacuum Cleaners, Accessories, Hobs, Microwaves, Hoods or Coffee Machines.
- 2.Retail price includes 23% VAT.
- 3.Additional digital offer from Miele & Cie. KG. All smart applications are made possible with the Miele@home system. The range of functions can vary depending on the model and the country.
We reserve the right to make technical changes; we assume no liability for the accuracy of the information provided.
