MasterCool refrigerator
K 2802 Vi
For high-end design and technology on a large scale.
sale price€9,699.99
A contribution to recycling costs (PRF) of 5 EUR for large domestic appliances and 10 EUR for American Side by Side refrigeration is Included in the retail price. No fees apply to Vacuum Cleaners, Accessories, Hobs, Microwaves, Hoods or Coffee Machines.
Retail price includes 23% VAT.
You can select the following services for this product in your basket:
- Freestanding Installation (€50.00)
- Built-In Installation (€70.00)
- WEEE Collection (€0.00)
Product details
- Push2openfor convenient door-opening assistance
- Food stays fresh for up to 3 x longer thanks toMasterFresh
- Light floods the interior thanks to LED elements –BrilliantLight
- Convenient control thanks to colour touch displayMasterSensor
Refrigerator
Built-in appliance
Integrated appliance
Door hingeright
Convertible door hinging
Side-by-side enabled
LightingBrilliantLight
Networking with Miele@home
Freshness systemMasterFresh
DynaCool
SoftClose
SelfClose
Push2open
FullAccess
EasyClean
MaxLoad hinge
Operating conceptMasterSensor
Automatic SuperCool
No. of temperature zones2
Sabbath mode
Eco mode
Height-adjustable, full-width tempered glass shelves2
Number of VeggieBoxes1
No. of crisper drawers2
SlidingShelf
Door shelves for jars1
Door rack for bottles3
Energy efficiency class (A–G)E
Annual energy consumption in kWh165.71
Energy consumption in 24 h in kWh0.45
Lock function
Spill guard
Acoustic door alarm
Acoustic temperature alarm
Optical door alarm
Optical temperature alarm
Niche width in mm min.762
Niche width in mm max.765
Niche height in mm min.2134
Niche height in mm max.2164
Niche depth in mm629
Appliance width in mm756
Appliance height in mm2127
Appliance depth in mm610
Weight in kg155.50
Door hinge technologyFixed door
Max. door front weight – refrigerator, in kg27
Climate classSN-T
Refrigerator compartment in l467
including PerfectFresh zone in l69
Total usable capacity in l467
Acoustic airborne noise emission class (A–D)C
Sound emissions in dB(A) re 1 pW40
Current consumption (mA)3000
Voltage in V220.00-240.00
Fuse rating in A13
Number of phases1
Frequency in Hz50.00-60.00
Length of supply lead in m3
Replacing lampsService
Active AirClean filter
Available display languages via MultiLinguaenglish (CA)
EAN4002516336655
Active AirClean filter
Perfectly lit
MasterCool – BrilliantLight
Soft and attractive: high-quality LED strips offer perfect illumination and a beautiful lighting mood.
Protective storage for long-lasting freshness
MasterCool – MasterFresh
Ideal climate: food stays fresh for up to 3 times longer due to perfect temperature and humidity.
The perfect solution for a handleless design
MasterCool – Push2open
This unique appliance integrates perfectly into handleless kitchens, as the door opens when you press the front.
Protective storage for long-lasting freshness
MasterCool – MasterFresh
Ideal climate: food stays fresh for up to 3 times longer due to perfect temperature and humidity.
Safe handling guaranteed
MasterCool – MaxLoad hinges
Strong and robust: the door hinges are able to withstand high loads and make it easy to open large doors.
Perfect food storage
MasterCool – DynaCool
Storage freedom: a fan ensures a uniform temperature throughout the entire unit.
Convenient touch operation
MasterCool – MasterSensor
Convenient operation: numerous settings can be configured with the tap of a finger.
Perfectly lit
MasterCool – BrilliantLight
Soft and attractive: high-quality LED strips offer perfect illumination and a beautiful lighting mood.
The perfect solution for a handleless design
MasterCool – Push2open
This unique appliance integrates perfectly into handleless kitchens, as the door opens when you press the front.
Provides effective protection against odours
MasterCool – Active AirClean filter
Unadulterated aroma: the combination of active charcoal and natural chitosan effectively prevents odours.
Matching products and accessories
Downloads
Whether you are looking to replace an appliance or plan a new kitchen – you will find all the relevant installation drawings for your Miele appliance here. Please note that our products should only be installed and maintained by authorised experts. In the event of queries, please ring us for some no-obligation advice!
Descriptions
Opening angel 90°/115°, right side stop, MasterCool (Sketch) *footnote
A) Appliance door width, K 2601 Vi, K 2601 SF, KWT 2601 Vi, KWT 2601 SF, KWT 2661 ViS, KWT 2661 SFS: 677 mm (26 2/3 , inch);, K 2602 Vi, K 2602 SF, KWT 2602 Vi, KWT 2602 SF, KWT 2662 ViS, KWT 2662 SFS: 677 mm (26 2/3 , inch);, K 2801 Vi, K 2801 SF, KF 2801 Vi, KF 2801 SF: 829 mm (32 2/3 inch);, K 2802 Vi, K 2802 SF, KF 2802 Vi, KF 2802 SF: 829 mm (32 2/3 inch);, K 2901 Vi, K 2901 SF, KF 2901 Vi, KF 2901 SF: 982 mm (38 2/3 inch);, K 2902 Vi, K 2902 SF, KF 2902 Vi, KF 2902 SF: 982 mm (38 2/3 inch);, B) Furniture front (max. 38 mm) (1 1/2 inch), C) Door handle, D) Distance door to wall (without furniture front and door handle): , K 2601 Vi, K 2601 SF, KWT 2601 Vi, KWT 2601 SF, KWT 2661 ViS, KWT 2661 SFS: 296 mm (11 2/3 , inch);, K 2602 Vi, K 2602 SF, KWT 2602 Vi, KWT 2602 SF, KWT 2662 ViS, KWT 2662 SFS: 296 mm (11 2/3 , inch);, K 2801 Vi, K 2801 SF, KF 2801 Vi, KF 2801 SF: 363 mm (14 1/3 inch);, K 2802 Vi, K 2802 SF, KF 2802 Vi, KF 2802 SF: 363 mm (14 1/3 inch), K 2901 Vi, K 2901 SF, KF 2901 Vi, KF 2901 SF: 428 mm (16 7/8 inch), K 2902 Vi, K 2902 SF, KF 2902 Vi, KF 2902 SF: 428 mm (16 7/8 inch), E) ONLY valid for SF versions: A + 25 mm (1 inch)
Descriptions
Side-by-side, MasterCool, without partition wall, with heating mat (Sketch) (with footnote)
1) Heating mat KSK 2001 (EU, AUS, CN) or KSK 2002 (US, CA, MX, BR)
Descriptions
K2801Vi, K2811Vi, K2802Vi, K2812Vi, inner space, MasterCool, installation drawings
Installation drawings
Descriptions
K2801Vi, K2811Vi, K2801SF, K2811SF, installation, MasterCool, *footnote, installation drawings
1. View from the front, 2. Mains connection cable, L = 3000 mm (118 inch), 3. No water/ELT connections permitted in this area
Descriptions
Example for diminsioning Side-by-side-Combination MasterCool (Sketch) (*footnote) (only for EUROPE)
*Niche height, 1 = Side-by-side fitting kit including pre-installed side wall heating KSK 200x, 2 = Furniture plinth height 102 - 132 mm (the appliance feet can be adjusted up to 30 mm high), 3 = Total appliance niche width 1220 mm (458 mm + 762 mm)
Descriptions
Side-by-Side, MasterCool, footnote, installation drawings
1. KSK 2001/2002, 2. Device A, 3. Device B, A = niche device A, B = niche device B
Descriptions
KFP3005ed/cs, KFP3004ed/cs, Front panel, Front dimensions, MasterCool II, installation drawings
Installation drawings
Descriptions
Example for diminsioning Side-by-side-Combination MasterCool (Sketch) (*footnote) (only for EUROPE)
*Niche height, 1 = Side-by-side fitting kit including pre-installed side wall heating KSK 200x, 2 = Furniture plinth height 102 - 132 mm (the appliance feet can be adjusted up to 30 mm high), 3 = Total appliance niche width 1366 mm (604 mm + 762 mm) Open Source Licence
