MasterCool freezer
F 2813 Vi
For high-end design and technology on a large scale.
sale price€10,999.99
A contribution to recycling costs (PRF) of 5 EUR for large domestic appliances and 10 EUR for American Side by Side refrigeration is Included in the retail price. No fees apply to Vacuum Cleaners, Accessories, Hobs, Microwaves, Hoods or Coffee Machines.
Retail price includes 23% VAT.
Product details
- Push2openfor convenient door-opening assistance
- Light floods the interior thanks to LED elements –BrilliantLight
- Fresh ice cubes from theIceMakerwith mains water connection
- Convenient control thanks to colour touch displayMasterSensor
Freezer
Built-in appliance
Integrated appliance
Convertible door hinging
Side-by-side enabled
Networking with Miele@home
NoFrost
SoftClose
Operating conceptMasterSensor
SuperFreeze
Sabbath mode
Eco mode
Energy efficiency class (A–G)E
Annual energy consumption in kWh321
Energy consumption in 24 h in kWh0.791
Niche width in mm min.762
Niche height in mm min.2134
Niche depth in mm629
Appliance width in mm756
Appliance height in mm2125
Appliance depth in mm608
Weight in kg156
Door hinge technologyFixed door
4* freezer compartment in l445
Freezer capacity in kg/24 h23
Acoustic airborne noise emission class (A–D)D
Sound emissions in dB(A) re 1 pW42
Voltage in V220-240
Fuse rating in A10
Number of phases1
Frequency in Hz50-60
Length of supply lead in m3
Replacing lampsService
Available display languages via MultiLingua
- english (CA)
- english (AU)
- slovenščina
- latviesu
- deutsch
- 繁體中文
- english
- hrvatski
- slovenčina
- suomi
- pусский
- 日本語
- eesti
- bahasa malaysia
- srpski
- english (GB)
- italiano
- 中文
- română
- english (US)
- ελληνιкά
- nederlands
- svenska
- yкраїнська
- dansk
- 한국어
- français (FR)
- français
- čeština
- norsk
- magyar
- lietuviu
- français (CA)
- polski
- العربية
- türkçe
- español
- português
EAN4002516712664
Convenient touch operation
MasterCool – MasterSensor
Convenient operation: numerous settings can be configured with the tap of a finger.
Matching products and accessories
Downloads
Whether you are looking to replace an appliance or plan a new kitchen – you will find all the relevant installation drawings for your Miele appliance here. Please note that our products should only be installed and maintained by authorised experts. In the event of queries, please ring us for some no-obligation advice!
Descriptions
Opening angle 90°/115°, right side stop, MasterCool (Sketch) with footnote
A) Appliance door , F 2411 Vi: 525 mm (20 2/3 inch);, F 2412 Vi, F 2412 SF, F 2413Vi, F 2472 Vi, F 2472 SF: 525 mm (20 2/3 inch);, F 2671 Vi: 677 mm (26 2/3 inch); , F 2672 Vi, F 2672 SF: 677 mm (26 2/3 inch);, F 2812 SF, F 2812 Vi, F 2813 Vi: 829 mm (32 2/3 inch);, F 2912 Vi, F 2912 SF: 982 mm (38 2/3 inch);, B) Furniture front (max. 38 mm) (1 1/2 inch), C) Door handle, D) Distance from the door to the wall (without furniture front and door handle): , F 2411 Vi: 237 mm (9 1/3 inch);, F 2412 Vi, F 2412 SF, F 2472 Vi, F 2472 SF: 237 mm (9 1/3 inch);, F 2672 Vi, F 2672 SF: 296 mm (11 2/3 inch);, F 2811 Vi: 363 mm (14 1/3 inch);, F 2812 SF, F 2812 Vi: 363 mm (14 1/3 inch);, F 2912 Vi, F 2912 SF: 428 mm (16 7/8 inch);, E) ONLY valid for SF versions: A + 25 mm (1 inch)
Descriptions
F2802Vi, F2812Vi, F2813Vi, F2812SF, F2801Vi, F2811Vi, F2811SF, installation, MasterCool, installation drawings
1. View from the front, 2. Mains Connection cable, L = 3000 mm (118 inch), 3. Water inlet positon, L = 2000 mm (not for KON USA), 4. No water/ELT conections permitted in this area
Descriptions
Side-by-Side, MasterCool, footnote, installation drawings
1. KSK 2001/2002, 2. Device A, 3. Device B, A = niche device A, B = niche device B
Descriptions
KFP3005ed/cs, KFP3004ed/cs, Front panel, Front dimensions, MasterCool II, installation drawings
Installation drawings
Descriptions
F2812Vi, F2813Vi, F2802Vi, F2811Vi, F2801Vi, MasterCool, inner space, installation drawings
Installation drawings
Descriptions
Side-by-side, MasterCool, without partition wall, with heating mat (Sketch) (with footnote)
1) Heating mat KSK 2001 (EU, AUS, CN) or KSK 2002 (US, CA, MX, BR) Open Source Licence
DownloadsPDF
- 1.A contribution to recycling costs (PRF) of 5 EUR for large domestic appliances and 10 EUR for American Side by Side refrigeration is Included in the retail price. No fees apply to Vacuum Cleaners, Accessories, Hobs, Microwaves, Hoods or Coffee Machines.
- 2.Retail price includes 23% VAT.
- 3.Additional digital offer from Miele & Cie. KG. All smart applications are made possible with the Miele@home system. The range of functions can vary depending on the model and the country.
We reserve the right to make technical changes; we assume no liability for the accuracy of the information provided.
